Lead Time: Approximately 30 business days
Capacity: 40-110m³/h
Screening surface: 16.71m²
Weight: max. 3220kg
Processed materials: Compost, Concrete, Demolition Waste, Gravel, Rock, Sand, Soil, Stone, Topsoil.
Factory Direct Shipping to Oceania, EU, and the US, Globally
This static trommel screen is designed for fixed screening applications, ensuring precise separation of gravel and sand with minimal waste, catering to the needs of various construction and mining projects.offering a reliable and efficient solution for various industries such as manufacturing, construction, energy, and mining.，With a weight of 3200 kg and dimensions of 5800x1900x2100 mm, this product is built to last, providing a robust and sturdy performance.
Key benefits include with a 1-year warranty on core components, large processing capacity, adopting special screening mesh, with high screening efficiency and long service life，stable operation with low noise, equip the Nylon brush, mesh holes are not easily blocked, easy maintenance and easy to replace screen.
| Technical data | ||
| Production capacity (m³/h) | (depending on material) 40-110 m³/h | |
| Trommel | Single and double trommel customization | |
| Trommel diameter (mm) | 1500 | |
| Trommel length (mm) | 4500 | |
| Screening area approximately (m²) | ≈16.71 | |
| Wire screens | interchangeable | |
| Outer meshes from (mm) | 2 - 80 | |
| Feeding hopper | Feed hopper length (mm) | 1400 |
| Feed hopper width (mm) | 833 | |
| Volume (m³) | ≈0.5 | |
| Transportation dimensions | Transportation status length (mm) | 5730 |
| Transportation status width (mm) | 1860 | |
| Transportation status height (mm) | 2050 | |
| Weight (kg) | ≈3220 | |
Features a simple structure for reliable and consistent performance.
Compact design saves space while maintaining high screening efficiency.
Lightweight build ensures easy relocation for flexible operations.
Low investment cost makes it ideal for budget-conscious projects.
Perfect choice for small garden work and home material screening.
User-friendly design allows quick screen changes and minimal downtime.
Latest Price List/Free Customized Solution/Maintenance & Installation Guide
Customize different models according to your needs (Small, medium, and large machine).
We have three production bases, guarantee 100% factory price of all products, and support export to all over the world.
We have professional customer service staff, ready to answer your questions about our products.
